Arrma Outcast 4S BLX Brushless RTR 1/10 Stunt Truck (Bronze) w/STX2 2.4GHz Radio

The Arrma Outcast 4S BLX Brushless RTR 1/10 Stunt Truck is equally suited to the trails, muddy fields, skate parks or race tracks. The OUTCAST 4X4 4S BLX shares the low, lean look of its 6S BLX forerunner in a scaled-down size. Power comes from the ARRMA 4S-capable BLX120 brushless system – which features a 2400Kv brushless motor and ESC fitted with dual EC5 connectors for using two 2S LiPo battery packs. Differential gears inside the front and rear gearboxes are made of durable metal.

Building from the successful 4X4 3S BLX platform, ARRMA designers stretched the track width for the OUTCAST 4X4 4S BLX by widening the suspension and drive shafts. A center brace added along the length of the chassis provides maximum durability and can be removed in just four quick steps when it’s time to perform maintenance. The molded 16mm Big Bore shocks include top-loading springs and molded-in shock rod ends to prevent spring loss. The large, tough wheels hubs and durable 17mm wheel hexes hold standard 3.8″ wheels, outfitted with low-profile BACKFLIP tires.

The ready-to-run package comes complete with a Spektrum STX2 2.4GHz radio with SRX200 waterproof receiver and an ARRMA ADS-15M metal gear servo. Add your choice of battery, charger, and “AA” transmitter batteries, and start making your own RC mayhem!





• ARRMA® speed and toughness
• 4S-capable BLX120 Brushless Power System for 50+ mph speed
• Performance approaching the OUTCAST™ 6S BLX 4X4
• Spektrum™ STX2® 2.4GHz Radio System
• 2-Channel SRX200 waterproof receiver *
• Built-in 3-position throttle limiter
• Extended range and interference-free performance
• Throttle/steering reversing
• Throttle/steering travel adjust
• Throttle limiting
• ADS-15M waterproof metal gear servo *
• 2400Kv Brushless motor with large heatsink
• BLX120 ESC with dual EC5™ battery connectors for two 2S LiPo packs
• Lengthened suspension arms and driveshaft for wider track than 3S BLX vehicles
• Center chassis brace for maximum durability
• Metal spur gear and castellated slipper pads
• Enlarged front and rear hubs for added strength
• Durable 17mm hexes
• 16mm Big Bore shocks with molded-in shock rod end and top-loading spring
• Front and rear gearboxes with metal internal differential gears
• Low-profile BACKFLIP tires
• ADS-15M metal gear servo
• 2-year limited warranty

Approximate Assembly Time: No assembly required

Ball Bearings: Transmission only

Batteries: One 3S, two 2S or one 4S hardcase LiPo battery (sold separately)

Body: Trimmed and painted molded polycarbonate

Bushing Material: Metal

Charger: Compatible with selected LiPo battery (sold separately

Chassis: Molded composite

Completion Level: Ready-To-Run

Differential: Oil-filled metal gear

Drivetrain: 4WD

Final Drive Ratio: 12.48

Front Shock Spring Rate: 0.8N/mm

Gear Pitch: 0.8 Module

Ground Clearance: 2.52″ (64mm)

Height: 8.43″ (214mm)

Internal Gear Ratio: 2.85:1

Length: 19.17″ (487mm)

Max Battery Dimensions: 6.14 x 2.00 x 1.89″ (156 x 51 x 48mm)

Motor Size: 3668

Motor Type: Non-sensored brushless, 2400Kv

Pinion: 13T

Radio: Spektrum STX2 2-channel included

Rear Shock Spring Rate: 0.7N/mm

Servos: Metal gear steering servo

Shock Type: Oil-filled, coil over spring

Size/Scale: 1/10

Speed Control: BLX120 w/dual EC5 battery connectors for two 2S LiPo packs

Spur Gear: 57T

Suspension: Independent

Tire Diameter: 6.06″ (154mm)

Tire Tread: dBoots BACKFLIP LP

Vehicle Type: Monster Truck

Water-Resistant: Yes

Weight: 8.25lbs (3.75kg)

Wheel Diameter: 3.82″ (97mm)

Wheel Hex Size: 17mm Hex

Wheel Type: MT

Wheelbase: 11.3″ (287mm)

Width: 15.83″ (402mm)

• (1) ARRMA OUTCAST™ 4×4 4S BLX Vehicle with
• (1) Spektrum SRX200 Waterproof Receiver (installed)
• (1) ARRMA® ADS-15M Metal Gear Servo (installed)
• (1) ARRMA® 4S-capable BLX120 Electronic Speed Control (installed)
• (1) ARRMA® 4S-capable BLX3668 Brushless Motor (installed)
• (1) Spektrum STX2® Transmitter
• (1) Product Manual
